Roton 780-157

Standard Duty Full Surface Continuous Hinge

Quick Product Details

  • Continuous Hinge
  • Full Surface
  • Standard Duty
  • LIMITED AVAILABILITY,PLEASE CALL 866-749-7661 FOR MORE INFORMATION.
Price: $170.00 /each

SKU: 780-157

Choose Options Below

This Roton 780-157 is a standard duty continuous hinge for medium frequency, standard duty applications. The hinge is full surface and installed flush with the top edge of the door. It can be used with doors made of any material.

  • Stock Item
  • Order in the next 3 hours 1 minutes to ship TODAY
  • FREE Same-Day ShippingWhen ordered before 2PM ET
  • No Hassle Returns
  • ×
    Getting shipping methods...

Have a question about this product?

Price: $170.00

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Size and Finish-RT:

Need Help Deciding? QH chevron down
83" Clear Anodized Aluminum
83" Dark Bronze Anodized Aluminum +$60.00
95" Clear Anodized Aluminum +$38.00
95" Dark Bronze Anodized Aluminum +$105.00

Help Me Decide

83" for 7 foot doors.

95" for 8 foot doors

Overview


Quality and Safety:
  • Meet requirements for positive pressure UL10C, UL10B and UBC7-2 Part 1
  • Lifetime warranty

Available Options: Choose Options Above

  • Size and Finish-RT: info icon

    • 83" Clear Anodized Aluminum
    • 83" Dark Bronze Anodized Aluminum
    • 95" Clear Anodized Aluminum
    • 95" Dark Bronze Anodized Aluminum

Product at A Glance

  • For surface applications where frame face dimension is limited
  • The frame leaf is mounted to the face of the frame and the door leaf is mounted to the face of the door with thru bolts
  • Can be used on doors of any material
  • Includes a security molding
  • Frame Reinforcement are required when weight exceeds 200 lbs.- use 16-gauge channel.
  • Includes Dril-Kwik (R) screws and thru-bolts
  • All Roton continuous geared hinges are surface applied
  • Installed flush with the top edge of the door
  • Recommended 1/8” for head clearance
  • Frame and door leaf alignment ribs for proper hinge and door location
  • Should in-the-field modifications be required, cut only from the bottom of the hinge. Do not cut through bearings or screw holes
  • Does not require door reinforcements
  • Any product modifications may void all warranties
Style Continuous hinge
Grade Standard Duty
Mounting Full Surface
Clearance 1/32" hinge side - plus standard lockside clearance
Inset 1/8"

More Info


Roton hinges actually serve to increase the lifespan of your door. It will also greatly reduce the amount you will need to spend on maintenance and repairs. This specific model is full-surface applied and installed flush with the top edge of the door. Roton hinges are designed to allow for its use on all door materials.
