Best 45H7D-14S-S1-626

Storeroom Function Complete Mortise Lock with Lever and Rose

Quick Product Details

  • Mortise Lock
  • Storeroom Function
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: 45H7D-14S-S1-626

Choose Options Below

This Best Access Systems 45H7D 626 is an ADA compliant, storeroom function mortise lock that conforms to ANSI/BHMA a 156.13 series 1000 Grade 1 standards for operation and strength, and Grade 2 standards for security.

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

  • Special Order
  • FREE Shipping

Have a question about this product?

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Finish:

626 Satin Chrome 626 Satin Chrome

Choose IC Core:

Best 1C7A1-7pin Uncombinated IC core with Best 1C7A1-7pin Uncombinated IC core with "A" keyway ready to be keyed +$35.00
No IC Core Needed

Help Me Decide

  • The Best Uncombinated IC core 1C7A1 must be keyed by a locksmith. No keys, keyblanks or control keys are included.


Special order non stock item with 4 week lead time
Quality and Safety:
  • Complies with ADA - American Disability Act.
  • The 40H series is listed by Underwriters Laboratories for use on a 3 hour A label doors.
  • ANSI A156.13, Series 1000, Grade 1 operation and strength, Grade 2 security.

Available Options: Choose Options Above

  • Finish:

  • IC Core: info icon

    • Best 1C7A1-7pin Uncombinated IC core with "A" keyway ready to be keyed
    • No IC Core Needed

Product at A Glance

Backset 2-3/4"
Handing Shipped right handed - field reversible
Door Thickness 1-3/4"
Strike - Standard strike 4-7/8" x 1-1/4" x 3/32" with 1-1/4" curved lip to center strike
- non-handed
Faceplate 8" H x 1-1/4" W
Body Size 5-7/8" H x 7/8" D x 4-1/16" W
Trim 14 style Lever and S style rose
Style Mortise lock
Function Storeroom Function:
- Key outside retracts latch only, door remains locked on the outside
- Inside lever is always free

More Info

Mortise locks, although challenging to install, have many advantages over cylindrical locks. Firstly, they are way more secure and vandal resistant than regular cylindrical locks since they are firmly fixed into the mortise of the door. They are also more aesthetically pleasing with an antique, neat look to add a special charm to your doors.



Instructions & Templates

Click on the links below to download helpful instructions & templates for this product

Scroll for More Product Information
