dormakaba 5010-SWL-26D-41

Special Order Simplex Extra Heavy Duty Mechanical Pushbutton Exit Device Lock

Quick Product Details

  • Mechanical Pushbutton Lock for Rim exit devices
  • Heavy Duty
Price: $563.00 /each
Special Order non-stock item Requires 6 week lead time

SKU: 5010-SWL-26D-41

Choose Options Below

This Kaba Access Control Simplex 5010 is a mechanical pushbutton lock with Schlage IC core key override prep for use with Rim exit devices. Cannot be used with mortise design or vertical rod Exit Devices

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

  • Special Order
  • FREE Shipping

Have a question about this product?

Price: $563.00

Choose Finish:

Satin Chrome - US26D Satin Chrome - US26D


Special order non stock item with 4 week lead time
  • Compatible with most leading brands of Rim Exit Devices (Exit Device and mounting hardware not included) . Universal mounting plate included simplifies installation and eliminates any requirement to stock different locks/plates for various Exit Devices.
  • Brushed Chrome Finish (26D)
  • Requires a Schlage compatible large format IC core for key override, not included.
  • ANSI/BHMA A156.2, Grade 1 Certified.
  • Three-hour UL/ ULC Fire rating for "A" label doors.
  • ADA compliant levers
  • 3 year limited warranty

Available Options: Choose Options Above

Product at A Glance

  • Compatible with most leading brands of Rim Exit Devices
  • The 5 numeric pushbuttons are constructed with anodized aluminum and are vandal resistant
  • Lock is programmed via keypad without removing the lock from the door
  • Combination code - one code per lock: one to five numbers pressed individually or simultaneously
  • This lock is weather resistant
  • Accepts Schlage large format interchangeable cores (Core not included)
Style Mechanical Pushbutton lock for Rim exit devices
Grade Heavy duty
Handing Pre-assembled for left-handed doors - easily field changeable
Door Thickness 1-3/4"
Backset Varies by exit device
Stile Minimum 5" required
Dimensions 8-7/8H x -4-1/4" W x 4-1/16" D

More Info

This exit device trim is compatible with these Rim exit devices.
Arrow S1250,Arrow S3883F/S3800,Cal Royal 9800,Cal Royal 2200,Corbin Russwin ED5200/5200A,Detex 1001 BP1,Detex 10/F10 Series,Precision 21/FL21,Sargent 2828,Sargent 3828,Sargent 8810E/8800
Sargent 8888,Von Duprin 22/22F,Von Duprin 98/98F,Von Duprin 99/99F,Von Duprin XP98/99,Yale YME2100/2100,Yale 7100.



Instructions & Templates

Click on the links below to download helpful instructions & templates for this product
