dormakaba E5010-BWL-626

Special Order E-Plex Digital Pushbutton Exit Device Lock

Quick Product Details

  • Digital Pushbutton Lock
  • Heavy Duty
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: E5010-BWL-626

Choose Options Below

This Kaba Access Control E-Plex 5010BWL is a battery operated digital push-button exit device lock with 100 codes and Audit trail. It is compatible with most leading brands of rim exit devices. The key override feature is prepped for Best type small format 6 or 7 pin Interchangeable cores.

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

  • Special Order
  • FREE Shipping

Have a question about this product?

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose IC Core:

1C7A1-7 pin Best Uncombinated IC core with 1C7A1-7 pin Best Uncombinated IC core with "A" keyway-ready to be keyed +$29.00
100CR/Contrl Ky-Keyed Arrow 6 Pin Small Format (Best type) Interchangeable Core + $34.00 100CR/Contrl Ky-Keyed Arrow 6 Pin Small Format (Best type) Interchangeable Core +$34.00
No IC Core Needed

Help Me Decide

  • The Best Uncombinated 7 pin IC core 1C7A1-7 must be keyed by a locksmith. No keys, key blanks or control keys are included.
  • Arrow brand Small Format Keyed 6 pin IC core, is keyed different with 2 keys and includes a control key which is required to install and remove IC core.


Overview

Special order non stock item with 8 week lead time.
Quality and Safety:
  • Grade 1
  • 3-hour, UL/ULC fire door rating for "A" labeled doors.
  • Meets requirements for Americans with Disabilities Act, ADA
  • 3 year limited warranty

Available Options: Choose Options Above

  • IC Core: info icon

    • 1C7A1-7 pin Best Uncombinated IC core with "A" keyway-ready to be keyed
    • 100CR/Contrl Ky-Keyed Arrow 6 Pin Small Format (Best type) Interchangeable Core
    • No IC Core Needed

Product at A Glance

  • For indoor/outdoor use
  • Locks are programmed via keypad or with optional Microsoft® Excel®-based software
  • 100 access codes can be used per door (upgrade to 300 via software)
  • Audit trail records 3,000 most recent locking events including use of the mechanical key override. Software is required to view audit events. (upgrades to 9,000 events with optional software)
  • The key override feature is prepped for Best type small format 6 or 7 pin interchangeable cores (core not included)
  • Battery operated with four AA Alkaline batteries which provide operation for up to 180,000 cycles
  • Authority Levels:
    • Master Level - performs all set-up and programming functions
    • Manager Level - administers common programming functions
    • Access User Level - Entry allowed with valid PIN
    • Service Level - codes for single event or single day access, programmable in advance
    • Maintenance Level - no access is granted, but information can be uploaded/downloaded to/from the lock
  • Code length: adjustable to accept 4 to 8 digits
  • Anti-tamper lockout: adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
  • Re-lock time: adjustable from 2 to 20 seconds
  • Cannot be used with mortise design or vertical rod exit devices
Style Digital Pushbutton lock
Used With Corbin Russwin ED5200/5200A, Cal Royal 9800 and 2200, Dorma 9300/F9300, Precision 21/FL21, Sargent 2828,3828,8800 and 8888, Von Duprin 22/22F, 98/98F, 99/99F, XP98/99, Yale 2100 and 7100 Exit Devices
Grade Heavy duty
Handing Pre-assembled for left-handed doors - easily field changeable
Door Thickness 1-5/8" to 2"
Backset 2-3/4" (standard)
Stile Minimum 5" required
Finish Satin chrome (626)

More Info


Kaba  E-plex series digital locks  are a simple way of ensuring the safety of your building by allowing each person the entry their status requires. This lock can even be programmed to allow single event or single day access. The audit trail feature keeps the 3,000 most recent locking event in memory for easy tracking of this lock.
