dormakaba TS9315-STH-693

Special Order Pull Side Spring Stop Hold Open Closer with Track Arm in Black Finish

Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: TS9315-STH-693

The Dorma TS9315-STH with Spring Dead Stop Pull side mount hold open closer with regular arm operating efficiency and track arm aesthetics. For interior and exterior barrier-free requirements, adjustable size 1-5.

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

QH phone left

Have a question? Need help?
Call Us: 1-866-749-7661

  • Special Order
  • FREE Shipping

Have a question about this product?

Overview

Special order non stock item with 4 week lead time
  • Hold open adjustable for degree of hold open and hold open force. Hold open is selectable on or off.
  • Slide track arm mounted on door, body on jam.
  • For pull side mount.
  • Sprayed black finish.
  • Adjustable spring size 1-5.
  • For interior doors from 3' to 4' wide.
  • For interior barrier-free requirements (Barrier Free- Opening force 5 lb or less on interior doors, 8.5 lb or less on exterior doors )

More Info

  • Adjustable backcheck
  • Adjustable delayed action
  • Adjustable sweep and latch closing speeds.
  • Non handed
  • Full metal cover standard
  • Sex nuts supplied standard for 1-3/4" thick door.
  • Adjustable for degree of hold open and hold open force.
  • U.L. and C.U.L. listed
  • ANSI A156.4 Grade 1.
  • Compliant with UL10C and UBC 7.2 (1997) for positive pressure
  • Meets the requirements of ANSI A117.1 and A.D.A. for barrier-free accessibility
  • CSFM and M.E.A. approved.

Reviews

Q&A

Instructions & Templates

Click on the links below to download helpful instructions & templates for this product

Scroll for More Product Information
