dormakaba TS9315PT

Push Side Closer with Steel Cam and Roller Design with Track Arm

Quick Product Details

  • Door closer
  • With Steel Cam and Roller Design with Track Arm
  • Push-Side Mount
  • Heavy Duty
Price: $573.00 /each

SKU: TS9315PT

Choose Options Below

This Dorma TS9315PT is a heavy duty push side mount surface closer. It is designed to operate with regular arm efficiency while still providing for track arm aesthetics. This product is non-handed and the spring size can be adjusted from 1-5.

  • Stock Item
  • Order in the next 7 hours 23 minutes to ship TODAY
  • FREE Same-Day ShippingWhen ordered before 2PM ET
  • No Hassle Returns
  • ×
    Getting shipping methods...

Have a question about this product?

Price: $573.00

Choose Finish:

628-Sprayed Aluminum 628-Sprayed Aluminum

Replacing Your Door Closer?

Product Finder

Overview


Suited for:
  • Interior and exterior doors

Quality and Safety:
  • Meets ANSI A156.4 Grade 1 requirements
  • Meets ANSI A117.1 and ADA requirements for barrier-free accessibility, (Opening force on interior doors: 5 lbs or less, on exterior doors: 8.5 lb or less )
  • U.L. & C.U.L. listed.
  • CSFM and M.E.A. approved
  • Meets UL10C and UBC 7.2 (1997).
  • 25 year limited warranty

Available Options: Choose Options Above

Product at A Glance

  • Steel cam and roller design with track arm
  • Adjustable backcheck
  • Adjustable delayed action
  • Adjustable sweep-speed and latch-speed
  • Adjustable spring size 1-5
  • includes a full metal cover
  • Furnished with sex nuts for 1-3/4” thick doors
Style Door closer
Mounting Push side
Door Handing Non-handed
Door Width - Interior: 2'6"- 4'
- Exterior: 2'6"- 3'6"

More Info


This cam and roller design closer will provide you with exceptional operating efficiency and pleasing track arm aesthetics to improve the quality of your opening. It is equipped with adjustable backcheck, delayed action, sweep speed and latch speed. Its spring size is also adjustable from 1 through 5 for flexibility to apply this closer in many different openings.
