Precision Hardware Special Order Apex Rim Exit Device with Night Latch Lever Trim Special Orders

Precision Hardware Special Order Apex Rim Exit Device with Night Latch Lever Trim Special Orders image 2

Precision Hardware 2114-R4914A-630-S301-3Ft

Special Order Apex Rim Exit Device with Night Latch Lever Trim

Quick Product Details

Rim Exit Device
Pasage Function With Lever
Heavy Duty

Get a Quote

Special Order non-stock item Requires 6 week lead time

SKU: 2114-R4914A-630-S301-3Ft

Choose Options Below

This Precision 2114-R4914A is a passage function Apex rim exit device. Package includes a lever and escutcheon. Lever always active.This device is supplied with standard hex key dogging.

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

Special Order
FREE Shipping

Have a question about this product?

Get a Quote

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Finish:

630-Satin Stainless Steel

Choose Handing:

Left Hand Reverse (LHR)

Right Hand Reverse (RHR)

Help Me Decide

Face the outside of the door to determine the hand. Here are some rules to follow:

The outside of an exterior door is the street or entrance side.
The outside of a room door is the hall side.
The outside of a single communicating door is the side from which the hinges are not visible when the door is closed.
The outside of a closet door is the room or hall side.

Doors equipped with exit devices swing out only, and therefore exit device handing is known as reverse bevel.

The door is Left Hand Reversed if:

• While you are standing outside of the room facing the door, the hinges are on your left side.

The door is Right Hand Reversed if:

• While you are standing outside of the room facing the door, the hinges are on your right side.

1 Choose Finish:
2 Choose Handing:
Qty.

Get a Quote
Have a question? Need help?
Call Us: 1-866-749-7661

Overview

Special order non stock item with 4 week lead time

Retrofit trim,designed to retrofit into other manufacturers mounting hole locations.
UL listed for panic hardware.
Certified to ANSI A156.3 Grade 1
Levers comply with ADA, Americans with Disabilities Act

Available Options: Choose Options Above

Finish:
- 630-Satin Stainless Steel
Handing:
Handing
Face the outside of the door to determine the hand. Here are some rules to follow:

The outside of an exterior door is the street or entrance side.

The outside of a room door is the hall side.

The outside of a single communicating door is the side from which the hinges are not visible when the door is closed.

The outside of a closet door is the room or hall side.

Doors equipped with exit devices swing out only, and therefore exit device handing is known as reverse bevel.

The door is Left Hand Reversed if:

• While you are standing outside of the room facing the door, the hinges are on your left side.

The door is Right Hand Reversed if:

• While you are standing outside of the room facing the door, the hinges are on your right side.
- Left Hand Reverse (LHR)
- Right Hand Reverse (RHR)

Product at A Glance

Package includes a lever and an escutcheon
The Apex wide stile exit devices accommodate doors with vision lites or glass windows where the vision lite frames or moldings project up to 1/4” beyond the face of the door
Functions are field selectable except for the Double Cylinder option
Furnished standard with machine screws and full thread wood/sheet metal screws

Style	Rim exit device
Grade	Heavy duty
Application	Single and double doors with mullion
Function	Passage function-Lever always active. No cylinder.
Handing	- Device is non-handed - Lever trim is handed
Door Thickness	1-3/4"
Dogging Feature	Hex key dogging standard
Strike	S301, stainless steel, black powder coated
Latch Bolt	Stainless steel deadlocking - 3/4" throw
Touchbar Height	39-15/16"- from floor (standard)
Stile	Minimum width 4-1/2"

More Info

Precision Hardware Apex rim exit devices are highly preferred and recommended by those in the know as the most aesthetically pleasing and efficient devices on the market. This specific model is equipped with a night-latch function lever for operation from the outside of the door opening with the use of a key.
