Sargent 28-10U65-LL-3

Special Order Heavy Duty Privacy Lever

Quick Product Details

  • Lever Set
  • Heavy Duty
  • Privacy/Bathroom Function
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: 28-10U65-LL-3

Choose Options Below

Sargent 10U65 is a privacy/bathroom function lever

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

  • Special Order
  • FREE Shipping

Have a question about this product?

Choose FINISH:

Polished Brass Polished Brass

Overview

Special order non tock item with 4 week lead time
Suited for:
  • Commercial and institutional heavy duty applications

Quality and Safety:
  • Exceeds ANSI/BHMA 156.2 series 4000 Grade 1 durability standards
  • UL listed to U.S.A. and Canadian safety standards; listed for use on 3-hour doors.
  • Positive Pressure - meets UL 10C and UBC 7-2
  • Meets ADA requirements for barrier free accessibility
  • 7 year limited warranty

Door preparation: (161 standard modified with 2 through-bolt holes)


Available Options: Choose Options Above

Product at A Glance

Style Lever set
Grade Heavy duty
Function Privacy/Bathroom Function:
- Push button on inside knob locks outside knob and is released when door is closed or inside knob is turned
- Emergency release on outside lever
- ANSI F76
Handing Non-handed
Backset 2-3/4"
Strike 4-7/8" curved-lip strike with a (standard) curved lip of 1-1/4" (ANSI A-115.2)
Latch 2-1/4" x 1-1/8" (stainless steel)
Throw 1/2"
Door Thickness 1-3/4" adjustable to 2"
Stile Minimum 4-1/2"
Design - Rose - L style
- Lever - L style

More Info


Convenience is important to you, and therefore it is important to us as well. The 10 line bored locks are designed with  you in mind. Installation can be done in one minute or less using the clear installation diagram that is prominently displayed on the box. The lever set is supplied with a simple-to-follow instruction sheet and the package is user friendly.
