Schlage B660P-606-EE-2.25THK

Heavy Duty Single Cylinder Deadbolt

Quick Product Details

  • Deadbolt
  • For wood or hollow metal exterior entrance doors
  • Heavy Duty
  • Single Cylinder
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: B660P-606-EE-2.25THK

Choose Options Below

This Schlage B660P-606 is a heavy duty single cylinder deadbolt that is operable via key on the outside or large thumbturn on the inside. It is designed for wood or hollow metal doors and it is finished with a satin chrome color. Used as reliable extra protection on exterior entrance doors or in areas where security is necessary to prevent unauthorized entrance.

  • Special Order
  • FREE Shipping

Have a question about this product?

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Backset:

2-3/4 2-3/4"
2-3/8 2-3/8"

Help Me Decide

The backset is the measured distance from the edge of a door to the center of the 2-1/8” bore hole.

Choose Cylinder:

Schlage C Keyway
Schlage C123 Keyway


Suited for:
  • Heavy duty commercial applications

Quality and Safety:
  • Meets or exceeds A156.5 Grade 1 strength and operational requirements
  • UL10B Listed auxiliary locks for A label single doors, 4' x 8'.
  • 3 year limited warranty

Available Options: Choose Options Above

  • Backset: info icon

    • 2-3/4"
    • 2-3/8"
  • Cylinder:

    • Schlage C Keyway
    • Schlage C123 Keyway

Product at A Glance

  • Deadbolt is thrown or retracted by key on outside or thumbturn on the inside
  • Large inside thumbturn makes it easy to throw and retract deadbolt
  • Includes Schlage cylinder with C123 or C keyway
  • For wood or hollow metal doors
  • High-strength steel alloy deadbolt with hardened steel roller resists sawing and kick-in attacks
  • Free-spinning, solid cylinder collar resists wrenching and prying
  • Hardened steel ball-bearings will protect mounting bolts from a drill attack
  • Metal shield protects the bolt from an ice-pick attack through the door
Style Single cylinder deadbolt
Finish Satin Brass (606)
Grade Heavy Duty
Throw 1"
Front 1-1/8" X 2-1/4" - square corner
Strike 1-1/8" X 2-3/4" - square corner
Door Thickness 2-1/4"

More Info

Deadbolts are often used as an extra measure of protection on outdoor entrances to  prevent unwarranted entrance. This deadbolt is single cylinder and is operable with a key in the outside and a thumbturn on the inside. This high quality lock protects againsts sawing, kick-in attacks, wrenching, prying, drill attacks and ice pick attack attempts.
