Magnetic Holders

About this Category

Electromagnetic holders are used to hold a door open until it is released by a smoke alarm system or from a remote device. They are often required by fire safety codes in fire rated applications. Browse through our selection of the best electromagnetic holders on the market.

Jump to a brand:

Rixson logo Sargent logo IEI logo

Rixson

view Rixson FM990 Low Profile (Flush) Electromagnetic Holder - Magnetic Holders

Rixson - FM990 Low Profile (Flush) Electromagnetic Holder

Starting at: $217.00

Rixson FM990 electromagnetic holder can be used in most remote door release applications. They are primarily used to hold smoke barrier doors open until released by a remote smoke detector or any other switching device. Holders must be used in conjunction with door closers.

  • Usage: Standard Duty
view Rixson FM998 Long Armature Wall Mount Electromagnetic Holder - Magnetic Holders

Rixson - FM998 Long Armature Wall Mount Electromagnetic Holder

Starting at: $217.00

This Rixson FM998 is a long armature wall mounted electromagnetic holder that has a holding force of twenty-five to forty pounds and a total projection of 3-5/8". This product is generally used to keep smoke barrier doors open unless they are released by a connected smoke alarm system or any other other remote switching device.

  • Usage: Standard Duty
view Rixson FM997 Short Armature Wall Mount Electromagnetic Holder - Magnetic Holders

Rixson - FM997 Short Armature Wall Mount Electromagnetic Holder

Starting at: $217.00

This FM997 is a short armature electromagnetic holder that gets mounted on the wall and has a total projection of 2-5/8". The wiring is concealed. Tri volt: 120VAC, 24VAC/DC and 12VDC. Mounting requires a 2" by 4" by 1-3/4" outlet box that is properly fastened.

  • Usage: Standard Duty
view Rixson FM996 Surface Electromagnetic Holder - Magnetic Holders

Rixson - FM996 Surface Electromagnetic Holder

Starting at: $230.00

This Rixson FM996 is an electromagnetic holder that has surface mounted wiring and requires 1-1/2" deep housing for the adapter and a well reinforced wall. This holder has a holding force of twenty-five to forty pounds and a total projection of four and an eighth inches.

  • Usage: Standard Duty
view Rixson FM993 Heavy Duty Wall Mount Electromagnetic Holder - Magnetic Holders

Rixson - FM993 Heavy Duty Wall Mount Electromagnetic Holder

Starting at: $422.00

This Rixson FM993 is a heavy-duty electromagnetic holder which has a holding force of three hundred pounds and gets mounted on a wall. Its voltage is 24VDC only and its wiring can be surface mounted or concealed. Fail safe operation will release door to close in the event of power loss.

  • Usage: Heavy Duty
view Rixson FM980 Floor Mounted Low Profile Electromagnetic Holder - Magnetic Holders

Rixson - FM980 Floor Mounted Low Profile Electromagnetic Holder

Starting at: $385.00

This Rixson FM980 is a floor mounted low profile electromagnetic door holder. It has twenty-five to forty pounds of holding force and covers 6-5/8" of floor space. Its wiring is concealed and it has tri-voltage of 120VAC, 24VAC/DC and 12VDC.

  • Usage: Standard Duty
view Rixson 900-50 1/2

Rixson - 900-50 1/2" Armature Extension*

Starting at: $34.00

This Rixson 900-50 is a 1/2 inch armature extension which will increase the distance between the armature face and the door face. Required the 900 Armature Base unit for use.

view Rixson 900-75 3/4

Rixson - 900-75 3/4" Armature Extension*

Starting at: $34.00

This Rixson 900-75 3/4" armature extension increases the distance between the face of the armature and the face of the door. Must be used in conjunction with the 900 armature base unit.

view Rixson 900-100 1

Rixson - 900-100 1" Armature Extension*

Starting at: $34.00

The Rixson 900-100 1" armature extension will increase the distance between the armature face and the door face. Requires the 900 Armature Base unit for use.

view Rixson 900-200 2

Rixson - 900-200 2" Armature Extension*

Starting at: $43.00

The Rixson 900-200 2" armature extension will increase the distance between the armature face and the door face. Requires the 900 Armature Base unit for use.

view Rixson 900-Z 90 Degree Bend Armature Extension* - Magnetic Holders

Rixson - 900-Z 90 Degree Bend Armature Extension*

Starting at: $64.00

This Rixson 900-Z is a swivelling armature extension that measures 1-1/2" and allows contact to move up to ninety degrees. This extension increases the distance between the door face and the armature face. Must be used with the 900 armature unit base.

view Rixson 900 Armature Extension Base Unit - Magnetic Holders

Rixson - 900 Armature Extension Base Unit

Starting at: $63.00

This Rixson 900 1-1/2" extension base unit will increase the distance between the armature face and the face of the door. Extension pieces must be used in conjunction with this 900 armature base unit. Allows contact to move 90 degrees offset.

view Rixson 998315 Replacement Cover Magnetic Holders - Magnetic Holders

Rixson - 998315 Replacement Cover Magnetic Holders

Starting at: $60.00

The Rixson 998315 is a replacement cover for FM997, FM998 & FM996 Magnetic holders.

view Rixson 997510 Armature Assembly - Magnetic Holders

Rixson - 997510 Armature Assembly

Starting at: $105.00

This Rixson 997510 is a replacement door armature for the FM980, FM981, FM990, FM991,FM996 and FM997 magnetic holders.

view Rixson 998512-689 Armature Assembly - Magnetic Holders

Rixson - 998512-689 Armature Assembly

Starting at: $110.00

This Rixson 998512-689 is a replacement door armature for the FM998 and 999 magnetic holders.

view Rixson 998369-3V Magnet Assembly and Bracket - Magnetic Holders

Rixson - 998369-3V Magnet Assembly and Bracket

Starting at: $158.00

This is a replacement multi-voltage magnet assembly with it's mounting bracket. As a replacment electrical item, it cannot be returned.

view Rixson 930106 Replacement Magnet for Smok-Chek V - Magnetic Holders

Rixson - 930106 Replacement Magnet for Smok-Chek V

Starting at: $137.00

Replacement magnet for Rixson's Smok-Chek V Electrified Closer/Holder. Because this is an electrified replacement part, it cannot be returned.

view Rixson 930105 Replacement Magnet for Smok-Chek V - Magnetic Holders

Rixson - 930105 Replacement Magnet for Smok-Chek V

Starting at: $137.00

Replacement magnet for Rixson's Smok-Chek V Electrified Closer/Holder.

Sargent

view Sargent 1561 Flush Mount Electromagnetic Door Holder - Magnetic Holders

Sargent - 1561 Flush Mount Electromagnetic Door Holder

Starting at: $200.00

This Sargent 1561 electromagnetic door holder is used on self-closing, fire and smoke barrier doors. It can be used independently or with any smoke detector system. This holder will fit a standard outlet box. It is a fail safe device which is a safety feature that will release a door in the event of power loss.

  • Usage: Standard Duty
view Sargent 1560 Surface Mount Electromagnetic Door Holder - Magnetic Holders

Sargent - 1560 Surface Mount Electromagnetic Door Holder

Starting at: $209.00

This Sargent 1560 is surface mounted, electromagnetic door holder for use on almost any remote door release application. They are primarily used to keep fire and smoke barrier doors open until they are released by a remote smoke detector or other switching device.

  • Usage: Standard Duty

IEI

view IEI PIP-12DC Plug-in Transformer - Magnetic Holders

IEI - PIP-12DC Plug-in Transformer

Starting at: $38.00

This IEI PIP-12DC is a plug-in transformer for use with Rixson FM series magnetic holders.

view IEI PIP-24DC Plug-in Transformer - Magnetic Holders

IEI - PIP-24DC Plug-in Transformer

Starting at: $38.00

This IEI PIP-24DC is a plug-in transformer for use with Rixson FM series magnetic holders.

More About Magnetic Holders

The primary use of electromagnetic holders is to hold smoke barrier doors open in applications where they only serve to prevent the spread of smoke and flames in case of an emergency. The holder will keep the door open at all times, unless it is activated by the fire alarm system it is connected to and it will release the door to close.

Another, less popular use of electromagnetic holders is as a security measure. It can be placed on a the door to a private room, such as an office, to hold the door open unless it is activated remotely to close.

22 items Scroll to see more below
