Corbin Russwin ML2057LL

Storeroom Mortise Lock Body

Quick Product Details

  • Mortise Lock Body
  • Storeroom/Closet Function

Price: $230.00 /each

Choose Options Below

This Corbin Russwin ML2057LL storeroom/closet mortise lock body is designed to work with lever trims. This package includes the lock body, an armored front, a strike and screw pack. A lever and cylinder are not included. It is for doors that are 1-3/4" thick.

  • In Stock!
  • Order in the next 20 hours 42 minutes to Ship TOMORROW
  • FREE Same-Day ShippingWhen ordered before 3PM ET
  • No Hassle Returns
  • ×
    Getting shipping methods...

Have a question about this product?

Price: $230.00

Choose Options

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Finish:

626 Satin chrome 626 Satin chrome
625 Polished Chrome 625 Polished Chrome
605 Polished Brass 605 Polished Brass
613 Dark Bronze 613 Dark Bronze


Quality and Safety:
  • Meets ANSI/BHMA A156.3 series 1000 Grade 1 operational and security requirements
  • Complies with ADA - Americans with Disabilities Act
  • 10 year limited warranty
  • Auxiliary latch deadlocks latchbolt

Available Options: Choose Options Above

Product at A Glance

  • Includes lock body, armored front, strike and screw pack
  • Levers and 1-1/8” mortise cylinder are not included
  • This body works with lever trim
Style Mortise lock body
Function Storeroom or Closet Function:
- Always locked on outside lever
- Requires a key for entry
- Inside lever is always free
- ANSI F07
Handing Field reversible
Door Thickness 1-3/4"
Backset 2-3/4"
Body Dimensions 5-7/8" x 4" x 15/16"
Strike ANSI standard 4-7/8" - 1-1/4" straight lip
Outside Front Plate 8" x 1-1/4" - accommodates flat doors and doors that are beveled 1/8"

Mortise locks are constructed for commercial and industrial applications. Since they are mortised into the door they can withstand a greater amount of abuse than standard bored locks. In addition, Corbin Russwin backs all ML2000 series mortise locks with a ten year limited warranty which should leave you worry-free for years to come.



Instructions & Templates

Click on the links below to download helpful instructions & templates for this product

Storeroom Mortise Lock Body
