LCN 4040XP-CUSH-SRI-628

Special Order Heavy Duty Cush Arm Adjustable Door Closer with SRI

Quick Product Details

  • Door closer
  • CUSH-N- STOP Arm
  • Heavy Duty
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: 4040XP-CUSH-SRI-628

This LCN 4040XP-CUSH-SRI Super Smoothee is a heavy duty door closer featuring the CUSH-N-STOP arm without hold-open. SRI,Rust Inhibitor.

QH phone left

Have a question? Need help?
Call Us: 1-866-749-7661

  • Special Order
  • FREE Shipping

Have a question about this product?

Overview

Special order non stock item with 12 week lead time.
Suited for :
  • High traffic commercial applications

Quality and Safety:
  • Tested and certified under ANSI Standard A156.4, Grade 1
  • UL and cUL listed for self-closing doors without hold-open
  • Closer meets ADA requirements



Product at A Glance

  • CUSH-N-STOP®, non-handed parallel arm features solid forged steel main arm and forearm with stop in soffit shoe
  • Adjustable from size 1 through size 6 and is shipped set to size 3
  • Closers will mount parallel arm (push side) w/PA Shoe on either right or left swinging doors
  • Mounting holes are  spaced 2-1/4” vertically and 1" horizontally
  • Cylinder is made of cast iron
  • Supplied with All-weather fluid
SRI This optional process is applied prior to the LCN powder coat finish and greatly exceeds ANSI/BHMA Standard A156.4 for corrosion resistance
Style Door closer
Handing Non-handed
Door Width - Interior doors: maximum 5'
- Exterior Doors: maximum 4'
Finish 628, Aluminum powder coated finish

More Info


LCN 4040XP series is designed with unmatched superior quality to ensure longevity even in applications which are subject to abusive conditions of the real world. The Cush-n-stop arm supplied with this specific package is a non-handed, parallel arm with a solid forged steel main arm and forearm with a stop in the soffit shoe.
