Sargent 7855-26D

Special Order Office or Entry Mortise Lock Body

Quick Product Details

  • Mortise Lock Body
  • Office or Entry Function
Get a Quote
Special Order non-stock item Requires 6 week lead time

SKU: 7855-26D

Choose Options Below

This Sargent 7855 is a mortise lock body package that includes the outside front, the curved lip strike and mounting screws but does not include the trim or the cylinder (requires 1-1/8" mortise cylinder).

Because this is not a stock item we must order it specifically for you and we will be unable to accept a return unless the item is defective as determined by the factory it was bought from.

  • Special Order
  • FREE Shipping

Have a question about this product?

Choose Finish:

US26D Satin Chrome US26D Satin Chrome

Overview

Special order non stock item with 4 week lead time
Suited for:
  • Commercial heavy duty applications

Quality and Safety:
  • ANSI/BHMA 156.13 series 1000 Operational Grade 1 and Security Grade 1 certified with all standard trims.
  • UL and UL listed to Canadian safety regulations; listed for use on 3-hour doors
  • 10 year limited warranty
  • Auxiliary deadlatch

Convenience:
  • Simple operation- only 30 degrees of lever rotation necessary to retract latch
  • Installation time greatly reduced due to pre-assembled components
  • Can be easily re-handed without disassembling components or removing case

Available Options: Choose Options Above

Product at A Glance

  • Includes outside front, strike and mounting screws
  • Does not include cylinders, levers or roses
  • Requires 1-1/8” mortise cylinder (not included)
Style Mortise lock Body
Function Office or Entry Function:
- Key in the outside lever retracts the latch bolt
- Lever inside will retract the latchbolt but will not unlock the outside lever
- Lever outside can be locked and unlocked by toggle only
Handing Handed-field reversible, shipped as RH
Strike 4-7/8" curved-lip strike with a (standard) curved lip of 1-1/4" - non-handed (ANSI A-115.1)
Latch 3/4" projection, stainless steel, one piece, anti-friction, reversible
Door Thickness 1-3/4"
Stile - 4-1/2" (minimum)
- 4-3/4" (minimum) for electrical function locks
Backset 2-3/4" (Standard)
Outside Front Plate 8" X 1-1/4" Adjustable to any angle from flat to beveled 1/8" in 2" (ANSI A115.1)
Body 4-3/32" deep X 5-31/32" high
