Sargent 8271

Electrical Fail Secure Mortise Lock Body

Quick Product Details

  • Mortise Lock Body
  • Electromechanical Fail Secure Function
SKU: 8271

Price: $426.00 /each

Choose Options Below

This Sargent 8271 is an electromechanical fail secure function mortise lock body that is designed to keep a door locked in case of power loss. As part of the 8200 Sargent lock series, it is a strong and durable lock, perfect for heavy duty applications in commercial areas such as hospitals, schools and universities.

  • In Stock!
  • Order in the next 18 hours 13 minutes to Ship TOMORROW
  • FREE Same-Day ShippingWhen ordered before 3PM ET
  • No Hassle Returns
  • ×
    Getting shipping methods...

Have a question about this product?

Price: $426.00

Choose Options

Start selecting options

Use the menu on the right to select available options.
After all options have been chosen, you can add to cart.

Choose Finish:

Polished Brass (US3) Polished Brass (US3)
Oil Rubbed Bronze (US10B) Oil Rubbed Bronze (US10B)
Polished Chrome (US26) Polished Chrome (US26)
Satin Chrome (US26D) Satin Chrome (US26D)

Choose SR 8200 RX Option:

No RX Option Required
Special Order RX Option +$97.00

Help Me Decide

  • Request to exit (RX) monitors access and/or egress through an opening through the use of a dry contact SPDT switch.
  • This is a special order item with 3 week lead time.

Choose Voltage:

12VDC
24VDC

Overview


Suited for:
  • Commercial heavy duty applications

Quality and Safety:
  • ANSI/BHMA 156.13 series 1000 Operational Grade 1 and Security Grade 1 certified with all standard trims.
  • UL and UL listed to Canadian safety regulations; listed for use on 3-hour doors
  • 10 year limited warranty
  • Auxiliary deadlatch
  • Fail secure

Convenience:
  • Simple operation- only 30 degrees of lever rotation necessary to retract latch
  • Installation time greatly reduced due to pre-assembled components
  • Can be easily re-handed without disassembling components or removing case

Available Options: Choose Options Above

Product at A Glance

  • Includes outside front, strike and mounting screws
  • Does not include cylinders, levers or roses
  • Requires 1-1/8” mortise cylinder (not included)
  • Fail safe- In the case of a loss of power, the strike will be unlocked
Style Solenoid activated mortise lock
Function Electromechanical Fail Secure Function:
- Key outside retracts the latch bolt unless the outside lever is locked
- Outside lever can only be locked by the solenoid
- Inside lever is always free
- Fail Secure security feature
Door Thickness 1-3/4"
Backset 2-3/4" (Standard)
Current .25A at 12VDC or .5A at 24VDC
Operating Temperature - Minimum: 151 degrees
- Maximum: 31 degrees
